M2 Software
¶
This section will discuss the software architecture of the M2 and explain the reference design available on the NREL GitHub at MODAQ2. For discussion on design decisions and details on technical aspects of the software design, please see the Technical Reference page.
Introduction¶
M2 has been designed around the ROS2 ecosystem of libraries and tools to provide users a well established way of developing a data acquisition system. ROS2 was selected because it is easy to learn with many free online training resources, completely free and open-source, supports multiple programming languages, and is reliable for long term use in industrial settings. There is also a plethora of already existing ROS packages that users can leverage in addition to the packages developed in the MODAQ 2 project.
The MODAQ 2 project is the amalgamation of ROS packages, tools, and guidance for developing data acquisition and control applications for marine energy devices using a ROS based architecture. The MODAQ 2 Reference Design includes several packages that are targeted for the marine energy sector and allow most developers with a basic background in programming to spin up a high-quality DAQ and control system.
The main software aspects of MODAQ 2 are as follows:
- Ubuntu Linux Operating System
- RO2 Humble Hawksbill
- Externally Developed ROS Packages
- MODAQ 2 Custom and Internally Developed ROS Packages
- Third Party DAQ Driver libraries
Note
It may be possible to run MODAQ 2 on newer versions of Ubuntu and ROS2 but they are not currently tested and supported.
Ubuntu 22.04 LTS¶
Because ROS2 Humble was selected as the ROS ecosystem, it is highly recommended that users work in the Ubuntu 22.04 operating system. Ubuntu is a free to use (for most applications) Linux distribution and has the best support for the ROS ecosystem. To get started working in Ubuntu, it is recommended to visit the Hardware page of this document to ensure that your controller meets the requirements of the MODAQ 2 design. After that, you can follow the instructions provided in Useful Links to install Ubuntu 22.04 Desktop on your controller.
ROS2 Humble Hawksbill¶
The Robotic Operating System (ROS) is a collection of middleware, libraries and tools that were designed to benefit the robotics development community. The qualities of ROS that benefit the robotics community also benefit the data acquisition and control for marine energy community. It provides an easy entry point for software development for data acquisition control but it also is very scalable and has the capabilities to do very advanced computational tasks if needed for a project. For example, after installing the ros-humble-desktop and MODAQ 2 packages, you can quickly run a process that collects and logs sensor data in mcap bag files for data analysis. However, if you need to build code that is deterministic or real-time, this is also possible with ROS but requires a much lower level understanding of computer programming and is likely not necessary for many applications. In summary, ROS is adaptable and extensible to meet the requirements of a data acquisition and control project.
The fundamentals of ROS are covered extensively in many online trainings, videos, whitepapers and classes, and we have collected our recommended starting places in the Useful Links page.
For MODAQ 2 usage, the main concepts to understand are as follows:
- Nodes: the software processes that make up a ROS system
- Packages: collections of nodes usually including all the necessary nodes to use a system component
- Topics, Messages, Publishers and Subscribers: how ROS nodes communicate with each other
- Middleware DDS: the background system that allows nodes to communicate reliably and with modularity
- Command Line Tools: useful tools to test and debug ROS systems
- Build System: colcon is used to build ROS2 packages
- Launch Files: files that define the startup and execution of a complete ROS system
- Parameters: configuration items that can modify how the ROS system operates
- Bag (mcap) files: data files that database the information collected and communicated through ROS
Requirements¶
The hardware requirements should be met before continuing with setting up the software requirements.
## Please follow the provided instructions for installing ROS2 but you can verify the install with this command:
sudo apt update
sudo apt upgrade
sudo apt install ros-humble-desktop ros-dev-tools ros-humble-rosbag2 ros-humble-rosbag2-storage-mcap nginx git curl linuxptp ros-humble-rosbridge-suite
Cloning the Repo¶
Follow the instructions described in M2 Github.
M2 Launch¶
The m2_launch package includes the python launch file which starts all the parallel processes (nodes) of the MODAQ 2 system. In m2_launch.py, the nodes of the system are specified and the config file is supplied. All ROS parameters of a node should be specified in the config file.
Note
The name of the node specified in the launch file must match the name of the node in the yaml config file. I.e. M2Supervisor in the launch file and the config yaml file.
Example launch and config files:¶
import yaml
import os
from launch import LaunchDescription
from launch_ros.actions import Node
from launch_ros.actions.node import ExecuteProcess
from datetime import datetime
from ament_index_python.packages import get_package_share_directory
#### PATH TO MODAQ CONFIG FILE ######
## FYI THIS PULLS THE FILE FROM THE INSTALL DIRECTORY, NOT THE SRC DIRECTORY
config = os.path.join(
get_package_share_directory('m2_launch'),
'config',
'm2_config.yaml'
)
def generate_launch_description():
return LaunchDescription([
Node(
package = "m2_supervisor",
executable = "m2_supervisor_node",
name = "M2Supervisor",
parameters = [config],
output="screen",
respawn = True
),
Node(...other nodes)
)]
M2Supervisor:
ros__parameters:
loggerPath: "/home/m2/Log"
loggerLimitBytes: 1000000
emailSendAddr: "youremailwithsmtpenabled@email.com"
emailSendPwd: "passwordhere"
emailGroup1:
- "youremail@email.com"
emailGroup2:
- "youremail2@email.com"
analyzedTopics:
- /ain_flap
- /T8din
topicErrorEmailSnooze: 60
The launch file and config files are moved once the build process is completed. To access these files, you must run source install/setup.bash in terminal. You should then be able to launch the file with the command ros2 launch m2_launch m2_launch.py. Executing this will start all the ROS nodes together. If this fails, errors will be reported in the terminal to assist you with troubleshooting.
MCAP Bag Data Files¶
The data collected by different nodes within MODAQ 2 is published on specific topics. This enables the data to be recorded and saved for future use. This is implemented by using the ROS2 bag recorder node and the mcap storage method. The ROS2 bag package can be installed by running sudo apt install ros-humble-rosbag2 ros-humble-rosbag2-storage-mcap in terminal. This is a useful tool for debugging robotic applications however, it is designed with enough reliability to function as a robust data recorder for data acquisition applications. The bag_recorded package in the MODAQ 2 reference design takes the rosbag2 API and adds some flexibility to it to allow for recording only specified topics as well as the ability to start and stop the recording programmatically.
Configuration¶
The bag_recorder_node is configured in the launch file configuration yaml file and includes the folder in which to save the bag files (mcap files). It includes the length of the files in seconds. It is best to break up the mcap files so they don't become too large and to reduce to possibility of corruption if the system crashes or power is lost. It also includes the logged topics. All topics in this list will be included in the bag files. You can also enable recording all topics by specifying "*" as the logged topics.
BagRecorder:
ros__parameters:
dataFolder: "/home/m2/Data"
fileDuration: 60
loggedTopics:
- /system_messenger
- /ain
- /do
- /T8din
Parsing mcap files¶
The mcap file format was designed by Foxglove and they also developed a GUI software that is able to process these data files and output plots, tables and other useful visualizers. For information on this GUI viewer, please see Useful Links.
To analyze the data, we recommend using the rosbags python package which is also able to parse the mcap files and generate numpy arrays which can be used for data analysis. This can be install with pip: pip install rosbags
Example Python code for parsing mcap files:
from rosbags.rosbag2 import Reader
from rosbags.serde import deserialize_cdr
import numpy as np
from matplotlib import pyplot as plt
from pathlib import Path
from rosbags.typesys import Stores, get_types_from_msg, get_typestore
import os
def get_all_file_names(folder_path):
try:
# List all files in the given folder
file_names = os.listdir(folder_path)
# Filter out directories, only keep files and return their full paths
file_paths = [os.path.join(folder_path, file) for file in file_names if os.path.isfile(os.path.join(folder_path, file))]
# Generate the modaq_messages/msg/{FILE_NAME} strings
modaq_messages = [f"modaq_messages/msg/{os.path.splitext(file)[0]}" for file in file_names if os.path.isfile(os.path.join(folder_path, file))]
return file_paths, modaq_messages
except Exception as e:
print(f"An error occurred: {e}")
return [], []
# Example usage
folder_path = r"C:\MODAQ\MODAQ2-RD-Dev\src\modaq_messages\msg"
file_names, message_types = get_all_file_names(folder_path)
print(file_names, message_types)
typestore = get_typestore(Stores.ROS2_HUMBLE)
add_types = {}
for i, name in enumerate(file_names):
print("name: ", name)
msgpath = Path(name)
msgdef = msgpath.read_text(encoding='utf-8')
print(msgdef)
add_types.update(get_types_from_msg(msgdef, message_types[i]))
typestore.register(add_types)
# create reader instance and open for reading
last_time = 0
last_timer = 0
dt_ros = []
dt = []
with Reader(r"./") as reader:
# Topic and msgtype information is available on .connections list.
for connection in reader.connections:
print(connection.topic, connection.msgtype)
# Iterate over messages.
for connection, timestamp, rawdata in reader.messages():
if connection.topic == '/ain_flap':
msg = typestore.deserialize_cdr(rawdata, connection.msgtype)
time = (msg.header.stamp.sec + (msg.header.stamp.nanosec/1e9))
dt_ros.append(time-last_time)
last_time = time
plt.plot(np.array(dt_ros)[100::])
plt.show()
MODAQ Messages¶
modaq_messages are custom messages that are used in MODAQ 2. ROS includes many message types by default but it was deemed necessary to build our own custom message types more applicable to our application of data acquisition. This ROS package has no nodes in it but it includes the CMake commands to turn the msg files into headers which can be referenced in different nodes. For example, /system_messenger uses modaq_messages/msg/systemmsg.hpp to define the type in different nodes. To use these custom messages, they must be included in the package.xml and the CMakeLists.txt file.
CMakeLists.txt:
find_packages(modaq_messages REQUIRED)
ament_target_dependencies(m2_supervisor_node rclcpp std_msgs modaq_messages rosbag2_cpp)
M2 Supervisor¶
The m2_supervisor is a package that was put in place to serve as the central process of MODAQ that enables some features that are very valuable to the marine energy industry. It includes features for logging events, sending emails and monitoring the health of the bag files being recorded.
Logger¶
The logger processes /system_messenger messages that have the log switch turned on and stores the information into a human-readable text file for diagnostics during operations.
Emailer¶
The emailer processes /system_messenger messages that have the email switch turned on and sends and email with smtp which contains the important information in a human readable format. For this to work, you must have an email with smtp enabled - this is possible with a free gmail account.
BagAnalyzer¶
Coming soon! This feature is still under development. The goal is to develop a process that monitors bag recording to ensure that all topics are being recorded as expected.
Labjack T8 ROS Package¶
The labjack_t8_ros2 package was developed specifically for use in MODAQ 2. This packages relies on a third party driver to interface with the Labjack T8.
Labjack LJM Library¶
MODAQ 2 Reference Design includes the Labjack T8 to make high-speed measurements up to 40 kHz. We have provided the labjack_t8_ros2 package to connected to T8 devices and stream data to ROS so it can be acted upon with control rules and/or logged for post-processing and analysis. To use the labjack_t8_ros2 package, the Labjack LJM library needs to be installed on your controller.
The instructions for installing this library are in {MODAQ 2 Repo}/src/labjack_t8_ros2/README.md
M2 Control¶
Currently the m2_control package just handles the interactions between the system and the HMI. The ROS2 ecosystem is well suited for more advanced control operations. A simple control alorithm could be implemented by creating a subsriber for the control rule input (i.e. the measurement of a battery voltage) with a callback class function. In the callback function, you could implement your algorithm (i.e. if voltage is too low, turn off a pump). The control could be actuated by then publishing a command to a digital output to turn something on or off (i.e. turning off the pump).
ROS2 also has built in control algorithms that you may find useful despite their main focus being on robot control. See the package ros2_control to learn about the advanced control options developed for use in ROS2.
Human-machine Interface¶
The HMI is described on the HMI page
Headless Operation¶
MODAQ 2 will often need to run headless or automatically start on the boot of the controller. This can be done with linux services.
Instructions for putting this in place can be found in {MODAQ 2 Repo}/service/README.md
Doxygen¶
The development of c++ documentation has started and is a work in progress. To view the c++ documentation made using doxygen, navigate to the docs folder and build using the bash command doxygen. More information is available in docs/README.md.
Once built, the doxygen documentation can be viewed on the nginx webserver by opening {M2_Controller_IP}/index.html
Precision Time Protocol¶
The precision time protocol or IEEE1588v2 or PTPv2 is a protocol used for synchronizing clocks on a network. While this can be done at the software level on the linux kernel, it is recommended to use a hardware implementation for synchronization in the microseconds. To do this, the network interface card (NIC) of your controller must officially support PTP. This can be determined with the model number of the NIC which can be determined with the command lspci | grep Ethernet which returns:
01:00.0 Ethernet controller: Intel Corporation I210 Gigabit Network Connection (rev 03)
03:00.0 Ethernet controller: Intel Corporation Ethernet Controller (2) I225-IT (rev 03)
The linux support for PTP can be installed using sudo apt install linuxptp. This enables the ptp4l tool which allows user interaction with the PTP hardware clocks on your controller's NIC.
